| Standard |
ASTM B564 / ASME SB564 |
| Size Chart |
1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000 |
| Standards |
API7S-15, API7S-43, API605, ANSI/ASME B16.5, B16.47 Series A & B, B16.48, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, BS4504, BS 10, EN-1092, DIN, ANSI Flanges, GOST Flange, ASME/ANSI B16.5/16.36/16.47A/16.47B, MSS S44, ISO70051, JISB2220, BS1560-3.1, EN1092 |
| Pressure Rating ANSI |
600 LBS, 900 LBS, 150 LBS, 2500 LBS, 300 LBS, 1500 LBS |
| Pressure Calculation in DIN |
16Bar 6Bar 25Bar 40Bar 10Bar / PN10 PN16 PN6 PN25 PN64 PN40 |
| JIS |
5K, 10 K, 16 K 20 K, 30 K, 40 K, 63 K |
| UNI |
6Bar 10Bar 16Bar 25Bar 40Bar |
| EN |
6Bar 10Bar 16Bar 25Bar 40Bar |
| Test Certificates |
EN 10204/3.1B
Raw Materials Certificate
100% Radiography Test Report
Third-Party Inspection Report, etc |
| Equipment |
Bending machine, Pushing Machine, Press machine, electric bevelling machine, Sand-blasting machine, etc |
| Production technique |
Forged, Heat treated, and machined |
| Coating |
Anti-rust Paint, Zinc Plated, Oil Black Paint, Cold, and Hot Dip Galvanized, Yellow Transparent |
| Most common types |
Forged / Threaded / Screwed / Plate |
| Connect Type/ Flange Face Type |
Ring Type Joint (RTJ), Flat Face (FF), Large Male-Female (LMF), Raised Face (RF), Lap-Joint Face (LJF), Small Male-Female (SMF), Small Tongue, Large Tongue & Groove, Groove |
| Special design |
As per your drawing
AS, ANSI, BS, DIN and JIS
15 NB (1/2″) to 200 NB (8″)
Equal and Reducing Configurations |
| Test |
Hydrostatic testing machine, X-ray detector, direct-reading Spectrograph, UI trasonic flaw detector, Magnetic particle detector |
| Manufacturer of |
ANSI DIN, GOST, JIS, UNI, BS, AS2129, AWWA, EN, SABS, NFE etc.
: -BS Flange, EN Flange, API 6A Flange, ANSI Flange, ASME Flange, DIN Flange, EN1092-1 Flange, UNI Flange, JIS/ KS Flange, BS4504 Flange, GB Flange, AWWA C207 Flange, GOST Flange, PSI Flange
B.S: BS4504 , BS3293, BS1560, BS10
German (DIN)
AS 2129: Table D; Table E; Table H
ANSI B16.5, ANSI B16.47, MSS SP44, ANSI B16.36, ANSI B16.48
ANSI : ANSI B16.5, ANSI B16.47(API605), MSS SP44, ANSI B16.36, ANSI B16.48
American standard (ANSI)
British standard (BS)
ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings
DIN: DIN 2527, DIN 2566, DIN 2573, DIN 2576, DIN 2641, DIN 2642, DIN 2655, DIN 2656, DIN 2627, DIN 2628, DIN 2629, DIN 2631, DIN 2632, DIN 2633, DIN 2634, DIN 2635, DIN 2636, DIN 2637, DIN 2638
The other standard: AWWA C207; EN1092-1, GOST12820, JIS B2220; KS B1503, SABS1123; NFE29203; UNI2276 |
