Bhadra Engimech is one of the most leading Lap Joint Flanges Manufacturers in Mumbai, India. ASTM A182 Class 150 Lap Joint Flanges products are designed and developed in accordance with international quality standards. One of our popular products in the Metal Market is Lap Joint Flanges. We are an ISO 9001:2015 certified company with a strong industry presence. We are offering market-leading prices on ASME B 16.5 to all our customers, with a stock of standard, grades, sizes, and types available for immediate delivery worldwide.
We are the world’s topmost Lap Joint Flanges Manufacturers in Mumbai, India. The performance and Dependability of Bhadra Engimech has made us the leading Stockholder, Manufacturer, Supplier, Importer, and Exporter in India. MSS SP44 products are mainly designed to control and help the flow of liquids, gases, or other materials. We offer different types of flanges such as Companion Flanges, Orifice Flanges and many more.
Lap Joint Flanges Specification
| Material of Construction | Standard | Grades |
|---|---|---|
| Stainless Steel Lap Joint Flanges | ASTM A182 , A240 | F 304, 304L, 304H, 316, 316Ti, 316H, 316L, 316LN, 309S, 309H, 310S, 310H, 317, 317L, 321, 321H, 347, 347H, 201, 202, 904L |
| Carbon Steel Lap Joint Flanges | ASTM A105 | Gr. F42,46,52,56,60,65,70 |
| Alloy Steel Lap Joint Flanges | ASTM A182 | F1,F5,F9,F11,F22,F91 |
| Nickel Alloy Lap Joint Flanges | ASTM SB564, SB160, SB472, SB162 | Nickel 200, Nickel 201, Monel 400, Monel 500, Inconel 800, Inconel 825, Inconel 600, Inconel 625, Inconel 601, Hastelloy C 276, Alloy 20 |
| Copper Alloys Lap Joint Flanges | ASTM SB 61 , SB62 , SB151 , SB152 | UNS No. C 70600 (Cu-Ni 90/10), C 71500 (Cu-Ni 70/30), UNS No. C 10100, 10200, 10300, 10800, 12000, 12200 |
| Low Temperature Carbon Steel | ASTM A350 | LF2 , LF3 |
| Duplex Steel Lap Joint Flanges | ASTM A182, A240 | UNS F 44, F 45, F51, F 53, F 55, F 60, F 61 |
Dimension Chart of Lap Joint Flanges
| Outside Diameter | Inside Diameter |
|---|---|
| ≤ 24 = 1.6 mm | > 24 = ± 3.2 mm | ≤ 10 = ± 0.8 mm | ≥ 12 = + 1.6 mm / - 0 mm |
| Diameter of Contact Face | Outside Diameter of Hub |
| 1.6 mm Raised Face = ± 0.8 mm 6.35 mm Raised Face, Tongue & Groove / Male-Female = ± 0.4 mm |
≤ 12 = + 2.4 mm / - 1.6 mm | ≥ 14 = ± 3.2 mm |
| Diameter of Counterbore | Drilling |
| Same as for Inside Diameter | Bolt Circle = 1.6 mm | Bolt Hole Spacing = ± 0.8 mm Eccentricity of Bolt Circle with Respect to Facing: ≤ 2½ = 0.8 mm max. | ≥ 3 = 1.6 mm max. |
| Thickness | Length thru Hub |
| ≤ 18 = + 3.2 mm / - 0 | ≥ 20 = + 4.8 mm / - 0 | ≤ 18 = + 3.2 mm / - 0.8 mm | ≥ 20 = + 4.8 mm / - 1.6 mm |
About Lap Joint Flanges
Lap Joint Flanges merchandise square measure used for associating and connecting pipes, pumps, valves, and far alternative instrumentality to make a piping system below the scale of two or four inches in diameter. The rim is employed to shut a pipeline in several industries. splice Flanges is once more like a vesture rim, however, splice Flanges encompasses a radius at the intersection of the bore and therefore the rim face to accommodate a lap stub ends. The face on the stub finish forms the seal face on the splice Flanges. this sort of splice Flanges is employed in applications wherever sections of piping systems ought to be demolished quickly and simply for review or replacement.
Lap Joint Flanges Application and Uses
- Lap Joint Flanges Uses in Textile machinery
- Lap Joint Flanges Uses in Oil and gas industry
- Lap Joint Flanges Uses in Medical Gas Pipeline Systems
- Lap Joint Flanges Uses in Pharmaceutical processing industry
- Lap Joint Flanges Uses in Fluid piping.
- Lap Joint Flanges Uses in Modern architecture.
- Lap Joint Flanges Uses in Water waste projects.
